Hosa Pro-Conex Sidekick Passive Direct Box

The Hosa DIB-443 "SideKick" is a passive direct injection transformer that changes guitar or bass signal to a low-impedance signal appropriate for sending down the snake to the house (or studio) mixing console's XLR inputs.

An "INST/SPKR" switch, when placed in the SPKR position allows an amplifier's extension speaker output to drive the line, thus preserving the original amp sound. A Ground Lift switch breaks ground to help trouble-shoot and terminate 60Hz "ground-loop" hum.

• Passive device, no power required
• Allows for connecting a electric guitar or bass directly into a mixer without losing tone due to impedance mismatch, long cables or cycle hum
• Converts any unbalanced line-level signal to balanced mic-level output
• Ground lift switch prevents ground-loop hum
• Ultra-compact, all-metal and road suitable housing

SPECIFICATIONS
Circuit Type: Passive (Transformer-Based)
Channels: 1 (Mono)
Connectors: 1/4 in TS to XLR3M
Inputs: 1 x 1/4″ TS (Unbalanced)
Outputs: 1 x XLR3M (Balanced)
Switches: INST/LINE
SKU: DIB-443
