Product Description
Scarlett 2i2 Studio ensures professional-level recordings of music. With the CM25 MkIII condenser microphone and ultra-low-noise mic preamps, you can capture finely detailed audio. Hi-Z inputs are ready to plug in guitars, while high-quality line ins easily connect keyboards and synths. SH-450 headphones let you monitor sound in clarity.
Equip yourself with Auto Gain and Clip Safe to ensure optimal levels. Capture a full-bodied sound with Air mode, Presence and Harmonic Drive. Also included is the Hitmaker Expansion software suite to help you throughout the recording, production and release processes.
Specifications
Number of Microphone Preamps — 2
Phantom Power — Yes
Instrument Inputs — 2
Line Inputs — 2
Air Mode — Yes
Auto Gain — Yes
Clip Safe — Yes
Line Outputs — 2
Headphone Outputs — 1
Loopback — Yes
Connectivity — USB Type-C
Protocol — USB 2.0
Form Factor — Desktop
Simultaneous I/O — 4 x 2 (including Loopback inputs)
A/D Resolution — 24-bit/192 kHz
Bus Powered — Yes (900mA)
Dimensions
Height — 47.5mm
Width — 180mm
Depth — 117mm
Weight — 0.595kg
Supported sample rates
44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
Microphone inputs
Frequency Response — 20-20kHz ± 0.06dB
Dynamic Range — 116dB (A-Weighted)
THD+N — -100dB @ 8dB gain
Noise EIN — -127dBu (A-Weighted)
Maximum Input Level — 16dBu
Gain Range — 69dB
Impedance — 3kΩ
Line inputs
Frequency Response — 20-20kHz ± 0.05dB
Dynamic Range — 115.5dB (A-Weighted)
THD+N — -100dB @ 8dB gain
Maximum Input Level — 22dBu
Gain Range — 69dB
Impedance — 60kΩ
Instrument inputs
Frequency Response — 20-20kHz ± 0.15dB
Dynamic Range — 113dB (A-Weighted)
THD+N — -80dB @ minimum gain
Maximum Input Level — 12dBu
Gain Range — 62dB
Impedance — 1MΩ
Line outputs (Balanced)
Frequency Response — 20-20kHz ± 0.02dB
Dynamic Range — 120dB
THD+N — -109dB
Maximum Output Level — 16dBu
Impedance — 100Ω
Headphone outputs
Frequency Response — 20-20kHz ± 0.1dB @ 33Ω / 300Ω
Dynamic Range — 112dB @ 33Ω
115dB @ 300Ω
THD+N — -99dB @ 33Ω | -108dB @ 300Ω
Maximum Output Level — 2.5dBu into 33Ω | 10dBu into 300Ω
Maximum Output Power — 32mW into 33Ω | 22mW into 300Ω
Impedance — 50Ω
Analogue to Digital Converter
THD+N — -110dB
Dynamic Range — 120dB
Digital to Analogue Converter
THD+N — -115dB
Dynamic Range — 130dB (A-Weighted)
Power
USB — 900mA
External (Optional) — 4.5W
Compatibility
Windows
Intel, AMD, and Arm64 processors supported
macOS
Apple Silicon and Intel processors supported
