Yamaha MG20 20-Channel Pro Audio Mixing Console
Yamaha MG20 20-Channel Pro Audio Mixing Console
Yamaha MG20 20-Channel Pro Audio Mixing Console
Yamaha MG20 20-Channel Pro Audio Mixing Console

Why Choose Yandas?

  • Image of FREE SHIPPING ON MOST ORDERS

    Free Shipping

    FREE SHIPPING ON MOST ORDERS
  • Image of PROTECH INSPECTION

    ProTech Inspection

    PROTECH INSPECTION
  • Image of SUPPORT TEAM STANDING BY

    Centrally Located In The USA

    SUPPORT TEAM STANDING BY
  • Image of 30-DAY RETURN POLICY

    30-Day Return Policy

    30-DAY RETURN POLICY

Yamaha MG20 20-Channel Pro Audio Mixing Console

SKU: MG20
  • 30 Day Return Policy
  • FREE SHIPPING Included

Why Choose Yandas?

  • Image of FREE SHIPPING ON MOST ORDERS

    Free Shipping

    FREE SHIPPING ON MOST ORDERS
  • Image of PROTECH INSPECTION

    ProTech Inspection

    PROTECH INSPECTION
  • Image of SUPPORT TEAM STANDING BY

    Centrally Located In The USA

    SUPPORT TEAM STANDING BY
  • Image of 30-DAY RETURN POLICY

    30-Day Return Policy

    30-DAY RETURN POLICY

For more than a century, Yamaha has been building a legacy of superior craftsmanship and innovation exemplified in all of our products, from an unrivalled catalog of world-class musical instruments to touring-grade professional audio. Now in its third incarnation, the MG Series embodies this pursuit of design excellence, and incorporates some of the same technologies developed for use in high-end professional consoles, including studio-quality preamps, powerful digital processing, and a rugged, reliable construction. With an intuitive, easy-to-use interface, the MG Series boasts an extensive lineup of compact mixing consoles with models ranging from six to twenty channels, suitable for a diverse range of users and applications. For installed, recording, or live music settings, the solid construction and flexible design of these consoles lets you shape your sound with confidence, continually delivering peak performance and a level of sound quality and reliability unrivalled in its class.

Features

  • 20-Channel Mixing Console
  • Max. 16 Mic / 20 Line Inputs (12 mono + 4 stereo)
  • 4 GROUP Buses + 1 Stereo Bus
  • 4 AUX (incl. FX)
  • “D-PRE” mic preamps with an inverted Darlington circuit
  • 1-Knob compressors
  • PAD switch on mono inputs
  • +48V phantom power
  • XLR balanced outputs
  • Internal universal power supply for world-wide use
  • Rack Mount Kit Included
  • Metal chassis
  • Dimensions(W×H×D): 444 mm x 130 mm x 500 m (17.5" x 5.1" x 19.7")
  • Net Weight: 6.9kg (15.2 lbs.)

Specs

  • I/O Phantom power +48V
  • Input Channels Mono[MIC/LINE] 12
  • Mono/Stereo[MIC/LINE] 4
  • Output Channels STEREO OUT 2
  • MONITOR OUT 1
  • PHONES 1
  • AUX SEND 4
  • GROUP OUT 4
  • Bus Stereo: 1, GROUP: 4, AUX: 4
  • Input Channel Function PAD 26 dB(Mono)
  • HPF 80 Hz, 12 dB/oct (Mono/Stereo: MIC only)
  • COMP 1-knob compressor (Gain/Threshold/Ratio) Threshold: +22 dBu to -8 dBu, Ratio: 1:1 to 4:1, Output level: 0 dB to 7 dB Attack time: approx. 25 msec, Release time: approx. 300 msec
  • EQ HIGH Gain: +15 dB/-15 dB, Frequency: 10 kHz shelving
  • EQ MID Gain: +15 dB/-15 dB, Frequency: Mono 250 Hz – 5 kHz peaking, Stereo 2.5 kHz peaking
  • EQ LOW Gain: +15 dB/-15 dB, Frequency: 100 Hz shelving
  • PEAK LED LED turns on when post EQ signal reaches 3 dB below clipping(Mono)
  • Level Meter 2x12 -segment LED meter [PEAK, +10, +6, +3, 0, -3, -6, -10, -15, -20, -25, -30 dB]
  • General specifications
  • Total harmonic distortion 0.03 % @ +14dBu (20 Hz to 20kHz), GAIN knob: Min, 0.005 % @ +24dBu (1kHz), GAIN knob: Min
  • Frequency response +0.5 dB/-1.5 dB (20 Hz to 48 kHz) , refer to the nominal output level @ 1 kHz, GAIN knob: Min
  • Hum & noise level Equivalent input noise -128 dBu (Mono Input Channel, Rs: 150Ω, GAIN knob: Max)
  • Residual output noise -102 dBu (STEREO OUT, STEREO master fader: Min)
  • Crosstalk -78 dB
  • Power requirements AC 100 – 240 V, 50 / 60 Hz
  • Power consumption 36 W
  • Dimensions W 444 mm (17.5")
  • H 130 mm (5.1")
  • D 500 mm (19.7")
  • Net weight 6.9kg (15.2 lbs.)
  • Accessories Included Accessory: Owner’s Manual, Technical Specifications, AC power cord, Rack-mount kit
  • Others Operating Temperature: 0 to +40˚C
Shipping This item ships to
Delivery Estimated between and . Will usually ship within 1 business day.
