*B-STOCK* AKG DPT800 Wireless Bodypack Transmitter | Band1 50mW

*** No returns, exchanges, or refunds on B-STOCK or USED items. This item is like-new and priced to go. Please message us if you have any questions about this product. ***

The DPT800 reference digital wireless body-pack transmitter, for use with the DSR800 wireless receiver, provides an ultra-wide bandwidth of 150 MHz and a selectable radio output power of 10- 50mW (depending on frequency band). For convenience and versatility, the transmitter can be programmed remotely via infrared data transmission from the DSR800 receiver, and signal security is ensured through the use of 512-bit encryption technology.

The DPT800 features an optional external mute/power switch that allows muting and on/off operation even when the transmitter is hard to access. The three-pin mini XLR audio input is compatible with any AKG lavalier and head-worn microphone and provides a bias voltage of 5V.

• Ultra-wide MHz bandwidth, ensuring stable transmission in highly-crowded RF environments
• Selectable radio output power (higher power fights interference at large venues)

• Audio encryption for complete signal security

• Compatible with AKG lavalier and head-worn mics

General Specifications
Carrier frequency range (country-dependent): Band 1 = 550.1 – 662.9 MHz
Switching bandwidth: ≤ 150 MHz (country-dependent)
Transmission power: 10, 20 mW (ERP max.), can be set via menu (country-dependent)
Scatter: ≤ -70 dBc
Antenna: λ/4 antenna
Audio input: 3‑pol. Mini‑XLR socket (3.0 Vrms max.)
Audio input gain: 0 dB, +10 dB, +20 dB switchable
Operating time: Up to 6.5 hours
